Telecom Bucket Trucks

OPTIONS & FEATURES:

◼ Insulated or non-insulated
◼ Splicer and walk-in basket options
◼ Customizable storage
◼ Walk-up tailshelf
◼ Inverter, generator options
◼ Rear cable/fiber splicing doors
◼ Service body with tall canopy
◼ Climate control work area
◼ Outlets & work table

Let us build a bucket truck made just for you.

DCP-36

◼ Telescopic articulating cable placer
◼ Non-insulated
◼ Max working height: 41′
◼ Max side reach: 26’6″
◼ Hot-dipped galvanized basket
◼ 400# side pull; 50# down pull
◼ Operates in stationary and mobile mode

DVS-29

◼ Telescopic bucket van
◼ Non-insulated
◼ Max working height: 34′
◼ Max side reach: 21′
◼ Single-person fiberglass basket
◼ Tons of secure storage options
◼ Workstation on Wheels option

DVT-29

◼ Telescopic aerial lift van
◼ Non-insulated
◼ Max working height: 34′
◼ Max side reach: 21’2″
◼ Single-person basket
◼ 350# basket capacity
◼ Transit cargo van

DTAX Series

◼ Telescopic articulating, personnel
◼ Max working height range: 44′ – 49′
◼ Max side reach range: 28′ – 30′
◼ Insulated (Cat. C or D) or non-insulated
◼ Fiberglass or aluminum basket
◼ 180 degree basket rotator
◼ Up to 400# basket capacity

DTA Series

◼ Telescopic articulating, personnel
◼ Max working height range: 40’ – 45’
◼ Max side reach range: 25’6” – 29’6”
◼ Insulated (Cat. C or D) or non-insulated
◼ Fiberglass or aluminum basket

DT-29

◼ Telescopic, personnel
◼ Max working height: 34′
◼ Max side reach: 22’3″
◼ Insulated (Cat. C or D) or non-insulated
◼ Fiberglass or aluminum basket
