Bucket Truck Builds Dur-A-Lift

DTA2 Series

◼ Single-person, personnel
◼ Insulated or non-insulated
◼ Fiberglass or aluminum basket
◼ End or side-hung basket
◼ Up to 400# basket capacity

Max working height / side reach:
    DTA2-40: 45′ / 29’6″
    DTA2-38: 43′ / 27’6″
    DTA2-35: 40′ / 27’6″

  • Specifications
  • Photos
  • Builds

DTA2 SERIES (35/38/40)

Models: DTA2-35, DTA2-38, DTA2-40
Product Overview
  • Telescopic articulating, personnel bucket truck
  • Compact design and stowing
  • Options available for use with 9′ body
  • Single-person, personnel
  • Insulated or non-insulated
  • Fiberglass or aluminum basket
  • End or side-hung basket
  • Up to 400# basket capacity
  • Max working height range: 40′ – 45′
  • Max side reach range: 25′ 6″ – 29′ 6″
Product Specifications
DTA2-35
Height to bottom of platform 35′
Working height 40′
Side reach (side hung) 25′ 6″
Side reach (end hung) 27′ 6″
Stowed travel height 10′
Basket capacity 400#
Approximate weight 2185#
Articulating arm travel -2 to 81
Main boom travel -25 to 75
Extension travel 110.5″



DTA2-38
Height to bottom of platform 38′
Working height 43′
Side reach (side hung) 25′ 6″
Side reach (end hung) 27′ 6″
Stowed travel height 10′
Basket capacity 400#
Approximate weight 2400#
Articulating arm travel 0 to 82
Main boom travel -25 to 75
Extension travel 110.5″



DTA2-40
Height to bottom of platform 40′
Working height 45′
Side reach (side hung) 27′ 6″
Side reach (end hung) 29′ 6″
Stowed travel height 10′
Basket capacity 350#
Approximate weight 2535#
Articulating arm travel 0 to 82
Main boom travel -25 to 75
Extension travel 122.5″
Standard Features

CONTROLS

Proportional controls
Non-proportional controls (DTA2S-35/38TS)
Lower controls with override
Engine start/stop from the basket
Individual control levers

HYDRAULIC SYSTEM

Rated pressure is 2200 PSI
Operating pressure is 2000 PSI
Open center hydraulic system

MECHANICAL SYSTEM

Telescoping articulating boom action
Offset main boom reduces travel height
Shear ball rotation driven
Fully enclosed worm gear box
Non-continuous rotation
Insulated extension boom (DTA2)
24”x24”x42” basket
Side hung basket

Options
  • Single hand joystick upper control
  • Outrigger or torsion bars
  • 12v D.C. backup
  • End hung basket
  • Basket offered in various sizes and configurations
  • Basket liner (DTA2)
  • Basket cover
  • Continuous rotation FULL PRESSURE SYSTEM
  • Tool trays of various sizes
  • Tool circuits
  • Tail shelf with walkup steps
  • Main boom fiberglass insert (DTA2)
  • Articulating arm fiberglass insert (DTA2)
  • Paint color
  • Insulated option available (DTA2S)
INSULATED OR NON-INSULATED

The DTA lift is available in insulated or non-insulated formats.

DTA2 – insulated (full pressure controls only) (Category D)
DTA2S – non-insulated (drive/battery, two speed or full pressure controls)

CUSTOMIZABLE

Ask about available chassis, body, basket, tail shelf, and accessory options to build the perfect bucket truck for your needs. Click the build tab to view DTAX2 builds or click request a quote to get started.
