DPM3 Series (AW)

◼ Auxiliary winch lifts up to 150#
◼ 36″x60″ aluminum basket
◼ Bottom mount basket
◼ Insulated or non-insulated
◼ 180-degree basket rotator

Max working height / side reach:
    DPM3-56: 60’8″ / 29’7″
    DPM3-51: 56’6″ / 30’6″
    DPM3-44: 49’5″ / 31’3″
    DPM3-40: 45’7″ / 27’3″

  • Specifications
  • Photos
  • Videos
  • Builds

DPM3 Series (AW)

Models: DPM3-40AW, DPM3-44AW, DPM3-51AW, DPM3-56AW
PRODUCT OVERVIEW
  • Telescopic articulating bucket truck
  • Auxiliary winch lifts up to 150#
  • 36″x60″ aluminum basket
  • Bottom mount basket
  • Insulated or non-insulated
  • 180-degree basket rotator
  • Max working height range: 45’ 7” – 60’ 8″
  • Max side reach range: 27’ 3” – 31’ 3″

SPECIFICATIONS
Product DPM3-40
Height to bottom of platform 40’7″
Working height 45’7″
Side reach 27’3″
Stowed travel height 10’5″
Platform capacity, using jib 400#
Platform capacity, not using jib 550#
Approximate weight 4000#
Articulated arm travel 0 to 81
Main boom travel -29 to 75
Extension Travel 96″



Product DPM3-44
Height to bottom of platform 44’5″
Working height 49’5″
Side reach 31’3″
Stowed travel height 10’5″
Platform capacity, using jib 400#
Platform capacity, not using jib 550#
Approximate weight 4100#
Articulated arm travel 0 to 81
Main boom travel -29 to 75
Extension Travel 120″



Product DPM3-51
Height to bottom of platform 51’6″
Working height 56’6″
Side reach 30’6″
Stowed travel height 10’5″
Platform capacity, using jib 400#
Platform capacity, not using jib 550#
Approximate weight 4400#
Articulated arm travel 0 to 74
Main boom travel -30 to 75
Extension Travel 120″



Product DPM3-56
Height to bottom of platform 55’8″
Working height 60’8″
Side reach 29’7″
Stowed travel height 11’6″
Platform capacity, using jib 400#
Platform capacity, not using jib 550#
Approximate weight 4500#
Articulated arm travel 0 to 74
Main boom travel -30 to 75
Extension Travel 120″
Standard Features
  • Proportional controls
  • Lower override controls
  • Engine start/stop from basket
  • Basket access from ground
  • Compensated upper boom
  • Insulated models available in Category D
  • Hydraulic basket leveling
  • Continuous rotation
  • Joystick and lockout controls
  • 180º basket rotator
Aerial Options
  • Outriggers
  • Fiberglass main and articulating booms
  • Tool circuits
  • D.C. backup system
  • Non-insulated versions available
  • 110 v outlet at basket (non-insulated only)
BASKET FEATURES (AW)
  • 400# basket capacity with jib in use
  • 550# basket capacity without jib in use
  • Auxiliary winch lifts up to 150 pounds
  • 36”x60” aluminum basket

*Also available with an SW style basket (no utility winch). Read more here.

INSULATED OR NON-INSULATED

The DPM3 lift is available in insulated or non-insulated formats.

DPM3 – insulated (Category D)
DPM3S – non-insulated

Customizable

Ask about available chassis, body, basket, tail shelf, and accessory options to build the perfect bucket truck for your needs. Click the build tab to view DPM3 builds or click request a quote to get started.
