DTA2S-35PC Splicer Build

This build features an Intelli-Core E-Drive Splicing Lab package with fully insulated floors, walls, and roof; non-skid flooring; walk-in rear door with window; 30 amp power plug; air conditioner and electric heater; roof vent; electrical cabinet with battery storage; interior and exterior lighting; interior and exterior outlets; drive system either lithium battery pack — a complete splicing lab package!

Fiber splicing, taken to new heights.

Dur-A-Lift’s DTA2 Series Aerial Lift with a Splicer Lab body features a telescopic articulating aerial lift providing 42 feet of working height. Designed with a spacious, climate-controlled Intelli-Core body, it offers a fully functional splicer lab environment for telecom crews. Intelli-Core structural composite body features fully insulated R11 floors, R9 walls, and a R15 roof—ensuring comfort and efficiency in all conditions. Power comes from the 51V EDrive System, featuring three 5.1 kWh lithium battery packs and a 4kW continuous (9kW peak) inverter. The system is complemented by a new proportional CAN bus control system for precise, variable machine function. Interior amenities include a 15K BTU air conditioner with heat pump, 1500W electric heater, perimeter LED lighting inside and out, multiple 110V outlets, USB charge ports, and a Bluetooth app-controlled switching system. Options include cable entry doors, additional outlets, beacon and strobe lights, and modular cabinetry layouts. This model is shown on a Ford F550 Diesel 4×4 chassis (19,500 GVWR, 7,500 GAWR front axle) with Intelli-Core body construction and fully welded aluminum sub-frame. The DTA2S-35PC is engineered for both high-reach access and a dependable mobile splicing workspace.

Elevated access for today’s fiber splicing demands.

SPLICER LAB AT A GLANCE

Check out this telescopic articulating aerial lift—available in insulated or non-insulated configurations—with a 40-foot working height and a built-in splicer lab that offers a spacious, climate-controlled, and fully functional workspace. See specs below.

• New Proportional Can bus Control allowing for precise, variable control of a machine’s function rather than just on/off.
• EDrive System, 51V: (Qty 3) 5.1 kWh Lithium Battery Pack, 4kW Continuous (9kW Peak) Inverter
• Chassis: Ford F550 Diesel 4×4 19500 GVWR 7500 GAWR FRONT AXLE
• Body: INTELLI-CORE

• Standard Specifications:
• INTELLI-CORE Structural Composite Construction
• Fully insulated R11 floor, R9 walls, and R15 roof
• Non-Skid Flooring
• Fully welded aluminum sub-frame
• Walk-In Rear Door w/ Window
• 30-amp shore power plug
• 15K BTU air conditioner w/ heat pump
• 1500W electric heater
• Roof vent w/ electric reversing fan
• Front electrical cabinet with battery storage
• Bluetooth app-controlled switching system
• All LED lighting inside and out
• Interior perimeter lighting
• Exterior perimeter work lighting
• Interior 110V outlet
• 12V charge port
• 2 x USB charge ports
• 45-amp power center (lithium compatible)
• Battery Charge Gauge w/ Disconnect Switch

• Options:
• 4 Stand Alone Cable Entry Door 16in x 16in Cable Door
• Exterior 120VAC Outlet Curb Side V Wall
• Interior 120VAC Outlet
• Roof Mounted LED Beacon Lights x 2
• 8 Surface Mount LED Strobes
• Rear Traffic Advisor
• 10ft Base Cabinet Layout; 17″ w/ 3 Drawers, 1 Door; 17″ w/ 5 Drawers
• Upper Cabinet, 2 Door; 36″ Upper Cabinet, 2 Door Street Side
• 24″ Upper Shelf; 24″ Upper Shelf Street Side
• 48 volt junction box with a 200 amp fuse.

This lift is part of Dur-A-Lift’s DTA2 series—a compact line of telescopic articulating bucket trucks offering working heights from 41 to 45 feet. Built for flexibility, the series offers a range of options including fiberglass or aluminum baskets, insulated or non-insulated designs, and multiple chassis, body, and tailshelf configurations. Whether you’re navigating narrow city streets, tackling routine maintenance, or updating your entire fleet, there’s a DTA2 model built to match your job. This specific build features a complete splicing lab.

Learn more about the DTA2 series here.
